As a kind of weighing equipment, digital electronic weighbridge mainly consists of weighing platform, weighing sensor and display instrument. The digital electronic weighbridge itself is a kind of weighing equipment, and its accuracy is critical, so it is very important for the debugging of the digital electronic weighbridge. If the weighbridge can be adjusted to a better state before verification, the next verification will be very easy, and the effect of getting twice the result with half the effort will often be achieved. The debugging of several main items of the weighbridge will be described below.
1. After the digital electronic weighbridge is debugged, the weight equivalent to large scale is evenly added to the digital electronic weighbridge bearing platform. After the displayed value is consistent with the weight value according to the position and method described in the instructions of various weighing displays, remove the weight and confirm that the empty scale displays "0". After that, the large scale shall be divided into several parts, which shall include the small scale, large scale and each weighing point where the tolerance changes. It is required that the weighing error of each point of the digital electronic weighbridge shall not be greater than the large tolerance requirement of each measuring point.
2. Use a digital voltmeter to measure the output voltage of each weighing sensor of the digital electronic weighbridge in turn. If there is no problem, adjust the corresponding two precision adjustable resistors in the junction box respectively to reduce the difference between them. However, attention must be paid to the adjustment amount. The rotation direction and rotation amount of the two regulators should be the same. When they rotate clockwise, their resistance decreases, the output voltage increases, and the displayed value increases. Otherwise, the opposite is true. Directly adjust to the output of each load cell of the digital electronic weighbridge.
The debugging can be carried out by weight method, that is, 1/10 of the large weighing weights are placed in the center of the digital electronic weighbridge bearing platform and on the bearing platform above each weighing sensor in turn, and the real difference method is used to accurately measure the difference of the output of each weighing sensor. At the same time, the two precision adjustable resistors corresponding to each weighing sensor of the digital electronic weighbridge are adjusted respectively, Reduce the difference between each other, but the direction and amount of rotation are also the same.
3. Refer to the technical specification of the digital electronic weighbridge weighing display, check the correctness of various function keys, and improve the weighing accuracy of the digital electronic weighbridge.
