At present, the weighbridge has been widely used in production and life to weigh people's means of production and life. However, in the long-term verification of the weighbridge, there are many problems in the installation of the weighbridge. This paper mainly introduces the construction requirements for the installation foundation of the weighbridge and the methods of lightning protection measures against the problems of the weighbridge.
1. Foundation construction requirements
There are generally two installation forms of the weighbridge, one is without foundation pit, the other is installed in the shallow foundation pit. The surface of the platform of the weighbridge in the shallow foundation pit can be flush with the ground, and the site looks barrier free and beautiful. The platform without foundation pit is higher than the ground, which is convenient for maintenance and low in cost. Generally, the platform without foundation pit is installed.
The concrete foundation of the weighbridge must be poured and the soft soil must be avoided. If another area cannot be opened due to the limitations of the site, it must be reinforced. At the same time, drainage facilities must be built to prevent the weighbridge from flooding into the water. During construction, the concrete grade shall be ensured, and the position of anchor bolts and cast iron baseplates shall be correct and the embedded parts shall not be displaced. The secondary grouting method can be used to locate the anchor bolts and cast iron baseplates. The levelness and elevation of each cast iron baseplate must meet the requirements of the design drawings. The height difference in the same plane is not more than 3mm.
2. Lightning protection measures
At present, microelectronics technology has been widely used in electronic weighing instruments, but it is extremely sensitive to external interference such as over-voltage, over-current, electromagnetic pulse and has extremely low tolerance. In order to ensure the stable operation of the system and prevent lightning damage, the measures in the design and installation of the weighbridge shall be determined according to the lightning stroke. Damage to electronic equipment caused by local overvoltage through electrostatic induction. According to relevant reports, this voltage can sometimes reach tens of kilovolts, which is enough to damage electronic products with poor grounding.
Install lightning rod. As an important measure of the lightning protection system, the lightning rod can also play an important role in the protection of the electronic truck scale system. In the design of the lightning rod, the length of the lightning rod should be determined according to the length of the truck scale, and the grounding work should be done according to the relevant standards.
Load cell protection. In the operation of the system, the weighing sensor plays an extremely important role, but it is also more sensitive to lightning, so all sensors should be protected and grounded. At the same time, a grounding pile or grounding grid should be installed below the grounding wire to quickly conduct the induced current. Jiangmen Lidong Electronic Weighing Instrument Co., Ltd. is a Jiangmen electronic weighing instrument manufacturer that specializes in the development and production of weighbridge, electronic weighing instrument, electronic truck scale, electronic ground scale, axle weight scale, industrial automatic packaging equipment, automatic batching equipment and other large-scale industrial weighing equipment. Looking forward to your cooperation!
